Double Side Rotary Tableting Machine Double Side Rotary Tableting Machine Double Side Rotary Tableting Machine Double Side Rotary Tableting Machine Double Side Rotary Tableting Machine Double Side Rotary Tableting Machine

Double Side Rotary Tableting Machine

344400.00 INR/Piece
Get a Price/Quote

Product Details:

  • Type Tablet Pressing Machine
  • Material contact parts SS
  • Capacity 100000 to 2500000 Pcs/min
  • Computerized No
  • Control Mode Automatic
  • Voltage 415 Volt (v)
  • Power 3 ph Volt (v)
  • Supply Ability : 10 Gross Per Month
  • Click to view more
Request To Call Back Send Inquiry
X

Price And Quantity

  • 344400.00 INR/Piece
  • 1 Gross

Product Specifications

  • 415 Volt (v)
  • Tablet Pressing Machine
  • yellow
  • No
  • contact parts SS
  • 36*28*42 Inch (in)
  • 3 ph Volt (v)
  • 1200 Kilograms (kg)
  • 100000 to 2500000 Pcs/min
  • Automatic
  • one years

Trade Information

  • 10 Gross Per Month
  • 07 Days
  • Box Packing
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • All India
  • Design is cGMP Square GMP moel Upper guard of transparent acrylic. Higher turret speed 40 rpm. Variable speed pulley. Lubrication system with hand pump, optional auto pump. All contact parts AISI 316 & non contact parts AISI 304. Turret drive trough worm and worm wheel gear. Rigid gravity feed frame and stand with fine flow setting of powder. Upper Punch penetration system to adjust upper punch entry in die. Completely Paint free tablet compression area. TECHNICAL SPECIFICATION Model VPM-12 VPM-16 VPM-20 VPM-22 Tooling Bolus / Slugging "D" "D" D No. of Station 12 STN 16 Stn. 20 Stn. 22 Stn. Operating Pressure 15 Ton 10 Ton 10 Ton 10 Ton Max. Tablet Diameter 42mm 24 mm 24 mm 24 mm Max. Depth of Fill 30 mm 20 mm 20 mm 20 mm Output - Tablets/Hr. 8,400 to 14,400 10,500 to 45,500 20,500 to 50,500 15,500 to 60,500 Upper Punch Penetration 1.5 to 4 mm 1.5 to 4 mm 1.5 to 4 mm 1.5 to 4 mm Main Electric Motor 7.5 HP/960RPM/ 415V/50HZ/3Ph 3HP/1440RPM/415V/50HZ/3Ph

Product Description

VENUS VTCMD4is asquare GMP model. Single sided Rotary Tablet Press suitable for medium sizebatch production. The VTCMD4 Tablet Press is designed in an effort to exceedthe highest cGMP requirement with use of advance technology and to ensure themost economical and efficient tablet production. The VTCMD4 Tablet Pressfeatures a unique ergonomic design. It is easy to operate, clean and maintain.

Product details

Capacity

129600 Tablet/Hr

Brand

Venus

Automation Grade

Automatic

Model Number/Name

DPM-B4-27

Frequency

50-60 Hz

Material

SS

Phase

3 Phase

Voltage

220-240 V

Weight

1350 Kg

Depth Of Fill

20 mm

Main Electric Motor

5 HP

Country of Origin

Made in India

Dimension

1200 mm x 1050 mm x 1800 mm

Power Speed

1440 RPM

Upper Punch Penetration

1.5 to 8 mm

Max Tablet Diameter

25 mm

Max Main Pressure

10 Ton
